FENNEL TAMBOUR DOORS

FENNEL TAMBOUR DOORS

Vertical Stile Covering in Picture <<<<<<NOT Available>>>>>>

*Extra wide Fascia shown is no longer available.

Thanks for choosing Tape-Ease! We ask that you put together a list of the Fennel components shown below that will make up your door. Please read through the information below........ The System: This simple system consists of interlocking tambour slats with a choice of interlocking handles. These parts are simply cut to the proper length and then interlocked one to the next. A couple of pieces of reinforced tape is then applied to the back to hold everything in place (supplied by customer).
The use of larger vertically opening tambour doors is now feasible by using the unique spring tension lifting mechanisms. Systems are available to control tambour doors up to 36” wide by up to 78” tall. The use of two mechanisms will control doors up to 48” wide by up to 78” tall.		A fascia profile is also available for use as either a stile or rail. It is simply attached to the end or top panel with screws. The Colors: The beauty of the product lies in its color choices. A true stainless steel look is now available in a plastic tambour. It is also available in silver metallic and semi gloss black which can be painted with new Spray Krylon TM Paint for plastics
This is a versatile tambour system with applications in many industries, including: Kitchens: With stainless steel gaining in popularity, our stainless steel transfer foil finish is perfect for appliance garages or full-height corner cabinet applications. Office Furniture: The product is ideal for large storage/file cabinets and desk “hoteling” systems. Trade Show Exhibits: Our durable pvc tambours are perfect for this high-traffic application. Recreational Vehicles: Ideal where weight and space issues are critical. Medical Cabinets: Perfect for cabinets storing chemical and cleaning agents.

Thanks for choosing Tape-Ease! We ask that you put together a list of the Fennel
components shown below that will make up your door. Than you can fax your order in using our
Quick Fax Order Form or E-MAIL US than call in your CCard. We will go over the list and call if there is
any questions. *See instructions below under each component picture...
$80 MINIMUM ORDER - $10.00 Packaging Charge per order on Fennel Tambour only.
( May be combined with other Tambour Products to reach minimum)
[CLICK HERE FOR INSTALLATION INSTRUCTIONS FOR FENNEL DOORS]

*These are 5/8" tall each. To figure out how many you need, divide your opening height by .625.
This will give you the total Slats you need. Than divide 96" by the door width. This will give you the
total FULL pieces that a 96" Slat will yield. Divide the total of slats needed by total FULL pieces that
a 96" Slat will yield for your door width. This will give you the total 96" Slats needed. 96" is the
only length that can be provided in any of the Fennel Tambour components.

	PART#	SLAT LENGTH	1 to 19 pc	20 to 59 pc	60 to 149 pc	150 + pc
Stainless Steel Foil	NP5605STS	96"	$6.94 ea	$6.37 ea	$6.01 ea	$5.81 ea
Silver Metallic Foil	NP5605SM	96"	$6.94 ea	$6.37 ea	$6.01 ea	$5.81 ea
Semi-Gloss Black	NP5605BL	96"	$6.18 ea	$5.87 ea	$5.67 ea	$5.04 ea

MOST ITEMS SHIPPED WITHIN 2 DAYS

*These handles come in 96" lengths only. 1 is needed per door. End Caps are required.

PART# LENGTH 1 to 5 pc 6+ pc

Stainless
Steel Foil NP5982STS 96" $25.96 ea $23.91 ea

Silver
Metallic Foil NP5982SM

Semi-Gloss
Black NP5982BL 96" $19.19 ea $17.60 ea

Right End Caps
Black/Grey NP3620(BL/GR) NA $2.00 ea $1.50 ea

Left End Caps
Black/Grey NP3621(BL/GR) NA $2.00 ea $1.50 ea

*This handle is made to accept a cabinet lock, it does not have a built-in lock.
A handle and a lock, or a handle with built-in lock can be used. (obtained by customer)
These handles come in 96" lengths only. 1 is needed per door. End Caps are required.

PART# LENGTH 1 to 5 pc 6+ pc

Stainless
Steel Foil NP5923STS 96" $26.23 ea $23.93 ea

Silver
Metallic Foil NP5923SM

Semi-Gloss
Black NP5923BL 96" $23.58 ea $21.56 ea

Right End Caps
Black or Grey NP3547(BL/GR) NA $2.00 ea $1.50 ea

Left End Caps
Black or Grey NP3548(BL/GR) NA $2.00 ea $1.50 ea

*For 96" Straight Tracks, you will need your door height, x 4. You may need to add more Straight Track if you do not want splices. If your cabinet depth is less than your door height, you will need 4 - 90deg corners per door so you can run the track along the top of your cabinet than down the back, otherwise, you need 2. Tracks only sold with a complete Fennel Tambour Door order.

PART# LENGTH 1 to19 pc 20 to 59 pc 60 to 149 pc 150+ pc

Black
Surface-Mount
Straight Track NP8681BL 96" $7.19 ea $6.75ea $6.40 ea $6.25 ea

Grey
Surface-Mount
Straight Track NP8681GR 96" $7.19 ea $6.75 ea $6.40 ea $6.25 ea

Black Surface-
Mount Track
Corners NP4829BL 90deg $3.00 ea $2.75 ea $2.50 ea $2.25 ea

Grey Surface-
Mount Track
Corners NP4829GR 90deg $3.00 ea $2.75 ea $2.50 ea $2.25 ea

$80 MINIMUM ORDER
( May be combined with other Tambour Products to reach minimum)

PART# LENGTH 1 to 19 pc 20 to 59 pc 60 to 149 pc 150+ pc

Black Recess-
Mount Track NP8453BL 96" $6.96 ea $6.38 ea $6.10 ea $5.80 ea

Grey Recess-
Mount Track NP8453GR 96" $6.96 ea $6.38 ea $6.10 ea $5.80 ea

Black Recess-
Mount Track
Corners NP4043BL 90deg $2.00 ea $1.75 ea $1.50 ea $1.25 ea

Grey Recess-
Mount Track
Corners NP4043GR 90deg $2.00 ea $1.75 ea $1.50 ea $1.25 ea

$80 MINIMUM ORDER
( May be combined with other Tambour Products to reach minimum)

*Our Facia Profile comes in 96" lengths only. 1 is needed per door.

	PART#	LENGTH	1 to 19 pc	20 to 59 pc	60 to 149 pc	150+ pc
Stainless Steel Foil Facia	NP5895STS	96"	$23.65 ea	$21.51 ea	$20.54 ea	$19.89 ea
Silver Metallic Foil Facia	NP5895SM	96"	$23.65 ea	$21.51 ea	$20.54 ea	$19.89 ea
Semi-Gloss Black Facia	NP5895BL	96"	$21.51 ea	$19.57 ea	$18.70 ea	$17.92 ea

LIFTING MECHANISMS
Lifting Mechanisms:
This system is key to the successful use of larger tambour doors operating in a vertical application. The systems allow for easy operating tambour doors with vertical heights from 24” to 78”. Typically, a door shorter than 24” will not require the system. When using a single system, tambour door slat lengths should not exceed about 36”.36" to 48" doors will require two systems. The system requires a shelf in the top of the cabinet for mounting of the main system parts. No functional elements are visible outside the cabinet. Indivdual systems are available to control vertical door heights of up to 27-1/2”, 55” and 78” by widths of up to 36” (slat length).
[CLICK HERE FOR INSTALLATION INSTRUCTIONS FOR FENNEL DOORS]

PART# DOOR HEIGHT 1 to 19 pc 20 to 59 pc 60 to 149 pc 150+ pc

Lifting
Mechanism NP4575 27-1/2" Max. $40.27 ea $38.77 ea $37.88 ea $36.69 ea

Lifting
Mechanism NP4555 55" Max. $42.02 ea $40.46 ea 39.53 ea $38.28 ea

Lifting
Mechanism NP4561 78-3/4" Max. $52.38 ea $48.89 ea 47.75 ea $46.26 ea

$80 MINIMUM ORDER - $10.00 Packaging Charge per order on Fennel Tambour only.
MOST ITEMS SHIPPED WITHIN 2 DAYS
[CLICK HERE FOR INSTALLATION INSTRUCTIONS FOR FENNEL DOORS]
